A131l Transmission Repair Manual
A131l Transmission toyota a131l repair manual - honestbeerguide - toyota a140e transmission rebuild manual toyota automatic transaxle a130l, a131, a131l,. Find best value and selection for your Toyota A245E A246E Transmission Service Repair Manual Corolla search on eBay. World's leading marketplace.
I have a 2000 VE Performa and a 2001 CE Corolla. I am looking for the Service Manual for the 1998-2002 Toyota Corolla 3FC A131L Tranny. What I am currently need in rush is the Torque Specification for the Transmission A131L Rear Cover. Planning to change the rear cover Gasket 0 on both. They both are leaking from the rear cover Gasket.
These are the 11 Bolts.for Tranny Rear Cover 35102 COVER SUB-ASSY, TRANSAXLE REAR 1. BOLT (FOR TRANSAXLE REAR COVER SETTING) 9ea. 0 PLANT NO.A32-1.25PX28-28 2ea. 6 PLANT NO.A32-1.25PX40-40 I Found that the A245E/246E has a spec of 7ft-lbs (10N.m/102Kgf-cm) for its 13 bolts. But not sure If I can use it.
Online Transmission Repair Manuals
BOLT (FOR TRANSAXLE REAR COVER SETTING) 2ea. 8 PLANT NO.M21, N11-1.00PX32-32 2 $0.83 11ea. 5 PLANT NO.M21, N11-1.0PX25-25 Bolts are different and the A245E uses ATV instead of gasket.So I think I can not use 7ft-lbs.
For tercel 1994 A132L it calls for 18ft-lbs on its 11 bolts. BOLT (FOR TRANSAXLE REAR COVER SETTING) 9ea. 0 PLANT NO.A32-1.25PX28-28 2ea. 6 PLANT NO.A32-1.25PX40-40 So I think this A130L is very similar to the A131L and the Bolts type and pattern are simillar.
The Gasket is different 0 or 20 and the Cover is the same 11bolts 35102 COVER SUB-ASSY, TRANSAXLE REAR 1. I found the Torque Tables for Toyota generic Bolts. Inspect my bolt and they say '6' or '9' and are Normal recess Hexagon Head Bolts with a socket size of 12mm and 'they should be 10mm in Dia' according other reads.
The Table calls for 29 ft-Lb if it is 6T or '6' or 51ft-lbs if it is 9T or '9'. Other Tables I have see calls for 6T 10mm 1.25 as to be torque fo 29ft-lb and 9T 10mm 1,25 to 51ft-lbs.
Transmission Repair Manuals Free
They do not take in cansideration the material where the Thread is cutted. In my case is Aluminum. Others tables as AutoZOne says that the range of a 6T shoul not exceed 32ft-lbs or bolt could break or break pitch but this is for steel cut treathed.
Not for Aluminum. I start thinking that the number of 18ft-lb for the A130L may be appilcable for my A131L and not the 7ft-lbs from the A245E.
But they still too low for the specs I found for same number 6T in Standard Tables, these tables apparently are for threads cutted on steel and not aluminun. I will be forced to remove one and try to read torque to remove it starting at 7ft-lbs. Then I will be able to measure Dia and pitch and take a closer look to see it it ia a 9T or a 6T. Nobody here have to deal with this cover before,They always leak A131L for Toyota Corolla 1998-2002. Mine are leakin long time ago both the same place.
Are you having problems fixing a A131L transmission? Are you looking for A131L transmission troubleshooting help, A131L rebuilding tips, A131L technical service bulletins, A131L diagnostics or technical information? Do you just have A131L questions and need some answers? Do you have diagnostic trouble codes (DTC's) and need A131L troubleshooting information? The is the place where the industries best transmission rebuilders work together to help solve the most complex automatic transmission problems.
Whether you need A131L wiring diagram information, A131L transmission rebuilders tips, A131L technical information, A131L diagnostics, A131L troubleshooting help, or just answers to your A131L transmission rebuilders question, the is the place to go!
